Motherboard MSI PRO B760M-E DDR5 LGA1700

http://compshop.co.il/en/hardware-and-software/motherboards/intel-motherboards/%D7%9C%D7%95%D7%97-%D7%90%D7%9D-msi-pro-b760m-e-matx-lga1700-en

Motherboard MSI PRO B760M-E DDR5 LGA1700
Product QR Code
  • SKU 55078
  • Brand: Msi
  • Product Code: 55078

  • ₪514

Motherboard MSI PRO B760M-E DDR5 LGA1700
Motherboard MSI PRO B760M-E DDR5 LGA1700

Description

Manufacturer: Msi, Socket: LGA1700, Chipset: B760, Memory Type: DDR5, Warranty: 3 years, Condition: New, SKU: 55078

Specification

Review
Warranty3 years
Service During The Warranty Period (Who To Contact)COMPMASTER Lab

073-2241747

Gei Oni 6, Tet Shoping Center, Ashdod

Manufacturer Part NumberPRO B760M-E
ModelPRO B760M-E
ColorDoes not apply
ConditionNew
EAN4895147145655
ManufacturerMsi
Audio

Realtek®&ALC897 Codec
7.1-Channel High Definition Audio

Back Panel Connectors
  • HDMI™
  • VGA
  • Keyboard / Mouse
  • USB 3.2 Gen 1 5Gbps (Type-A)
  • LAN port
  • Audio Connectors
  • USB 2.0
  • USB 2.0
ChipsetB760
Compatibility for computer assemblyIntel Motherboards
ConfigurationmATX
Dimensions200mmx236.16mm
Internal Ports / Inputs

1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
2x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 3.2 Gen1 Type A ports

Memory

2x DDR5, Maximum Memory Capacity 96GB
Memory Support DDR5 64+(OC)/ 62(OC)/ 6(OC)/ 58(OC)/ 56(JEDEC)/ 54(JEDEC)/ 52(JEDEC)/ 5(JEDEC)/ 48(JEDEC)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 64+ MHz
• 1DPC 2R Max speed up to 56+ MHz

Supports Intel®&XMP 3. OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory

SocketLGA1700
Storage
STORAGE1x M.2
M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
RAIDSupports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Wired CommunicationRealtek RTL8111H Gigabit LAN
סוג הזיכרוןDDR5
Link To The Manufacturer'S Website

Get full product information - Go to product page

Product LinkMotherboard MSI PRO B760M-E DDR5 LGA1700
Matching SKUsID: 55078, OC: 26739-05, AMT: 4711377125154, MPN: PRO B760M-E, EAN: 4895147145655

The price is valid as of 27.07.2025
