| Review | |
| Warranty | 3 years |
| Service During The Warranty Period (Who To Contact) | COMPMASTER Lab 073-2241747 Gei Oni 6, Tet Shoping Center, Ashdod |
| Manufacturer Part Number | A620M DS3H |
| Model | A620M DS3H |
| Color | black |
| Condition | New |
| Manufacturer | Gigabyte |
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| Back Panel Connectors | 1 x PS/2 keyboard/mouse port 1 x USB Type-C® port, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 port 4 x USB 2.0/1.1 ports 1 x HDMI port 1 x DisplayPort 1 x D-Sub port 1 x RJ-45 port 3 x audio jacks |
| Chipset | A620 |
| Compatibility for computer assembly | AMD Motherboards |
| Configuration | Micro ATX |
| Dimensions | Micro ATX Form Factor; 24.4cm x 24.4cm |
| Internal Ports / Inputs | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x Clear CMOS jumper |
| Memory | Support for DDR5 76(OC)/ 72(OC)/ 7(OC)/ 68(OC)/ 66(OC)/ 64(OC)/ 62(OC)/ 6(OC)/ 56(OC)/ 52/ 48 MT/s memory modules |
| Socket | AM5 |
| Storage | CPU: - 1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support) Chipset: - 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| Wired Communication | Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| סוג הזיכרון | DDR5 |
| Link To The Manufacturer'S Website | |
| Product Link | Motherboard Gigabyte A620M DS3H DDR5 Micro ATX AM5 |
| Matching SKUs | ID: 55993, OC: 27010-05, ML: 95A62010, MPN: A620M DS3H |
The price is valid as of 22.02.2025
