Motherboard Asus H110M-A/M.2 DDR4 LGA1151
http://compshop.co.il/en/hardware-and-software/motherboards/intel-motherboards/%D7%9C%D7%95%D7%97-%D7%90%D7%9D-asus-h110m-a-m-2-matx%C2%A0-lga1151-en
- SKU 43040
- Brand: Asus
- Product Code: 33575-05
₪273
Description
Manufacturer: Asus, Memory Frequency: 2400MHz, Socket: LGA1151, Chipset: H110, Memory Type: DDR4, Warranty: 3 years, Condition: New, SKU: 43040Specification
| Review | |
| Warranty | 3 years |
| Service During The Warranty Period (Who To Contact) | COMPMASTER Lab 073-2241747 Gei Oni 6, Tet Shoping Center, Ashdod |
| Manufacturer Part Number | H110M-A/M.2, 90MB0R60-M0EAY0 |
| Model | H110M-A/M.2 |
| Color | Does not apply |
| Condition | New |
| Manufacturer | Asus |
| Audio | Realtek ALC887/897 8-Channel High Definition Audio CODEC *2 - Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - LED-illuminated design - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors |
| Back Panel Connectors | 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x DVI-D 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 3.2 Gen 1 (blue) 4 x USB 2.0 3 x Audio jack(s) |
| Chipset | H110 |
| Compatibility for computer assembly | Intel Motherboards |
| Configuration | mATX |
| Internal Ports / Inputs | 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector |
| Memory Frequency | 2400MHz |
| Socket | LGA1151 |
| Storage | Intel H110 chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*2 4 x SATA 6Gb/s port(s), Intel Rapid Storage Technology supports*1 |
| Wired Communication | Intel I219V |
| סוג הזיכרון | DDR4 |
| What'S In The Box? | User´s manual I/O Shield 2 x SATA 3Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD |
| Link To The Manufacturer'S Website | |
| Product Link | Motherboard Asus H110M-A/M.2 DDR4 LGA1151 |
| Matching SKUs | ID: 43040, OC: 33575-05, CD: 90MB0R60-M0EAY0, MPN: H110M-A/M.2, MPN2: 90MB0R60-M0EAY0 |
The price is valid as of 21.05.2025
