Wireless N Router VoIP Gateway D-Link Wireless N Router Gateway 1*FXS

https://compshop.co.il/en/network-accessories/wireless-n-router-voip-gateway-d-link-wireless-n-router-gateway-1-fxs-en

SKU 65289
Brand: D-Link
Product Code: 65289

₪141

Description

Advanced wireless router compliant with 802.11n standard, offering fast and reliable connectivity for all devices at home or in the office. The device includes an FXS port that allows for telephony connection, enabling you to make high-quality phone calls over the internet. Additionally, the router is equipped with 4 LAN ports, allowing for direct connection of devices such as Computers, printers, and other devices to the local network. With 802.11n technology, you can enjoy faster data transfer and a wider reception range, ensuring a smooth browsing experience throughout the home. The router is easy to install and use, providing an ideal solution for anyone looking to upgrade their home or office network.

D-Link

10/100 Mbit

New

65289

Specification

Specification
Revew	WAN interface • 1 10/100BASE-TX Ethernet port for cable or DSL- modem or connect to a dedicated Ethernet- line LAN interface • 4-port 10/100BASE-TX Ethernet WLAN interface • IEEE 802.11n ( up to 300 Mbit / s) • IEEE 802.11b / g FXS interface • 1 FXS port to connect an analog phone or fax machine Frequency band • 802.11b: 2400 ~ 2484 MHz ISM band • 802.11g: 2400 ~ 2484 MHz ISM band • 802.11n ◦ HT20: 2400 ~ 2483.5 MHz ISM band ◦ HT40: 2422 ~ 2452 MHz ISM band Wireless speed • 802.11b: 11, 5.5, 2 and 1 Mbit / c for each channel, with automatic speed • 802.11g: 54, 48, 36, 24 , 18, 12 , 9 and 6 Mbit / s for each channel, with automatic speed • 802.11n ◦ HT20: up to 150 Mbit / s ◦ HT40: up to 300 Mbit / s Modulation schemes • 802.11b: CCK, DQPSK, DBPSK • 802.11g: 64QAM, 16QAM, QPSK, BPSK, DSSS • 802.11n: 64 QAM, 16QAM, QPSK, BPSK Software Basic functions SIP • Invite with Challenge • Register for IP-address SIP- server or domain name • Support the format of SIP URI (RFC3986) • Support for outbound (outbound) proxy • Timers sessions (update / re-invite) • Support for DNS SRV • Types of calls: Voice / Modem / Fax • User-configurable dial plan (dial plan) • Identify the source and destination (P2P- calls) manually • Dialing E.164 ( with an exclusion rule ENUM) Call functions • Direct call IP-to-IP without SIP proxy • Hold / resume a call • Call Waiting • Forwarding (unconditional , on busy , no answer ) • "Do not disturb" • Message Waiting Indication (MWI) • Lock Hidden Numbers • AntiAON • Speed Dial • "hotline" Voice features • Codecs : G.711 a / μ-law, G.729A, G.726, G.722 • DTMF detection and generation • Comfort noise generation (CNG) • Voice Activity Detection (VAD) • Variable (dynamic ) jitter- buffer • Generation of call progress tone (FXS) • Program Gain • In-band DTMF, out-of-band DTMF (RFC2833, SIP-INFO) • Support for tone / pulse dialing • Detection and generation Caller ID (Caller ID) • T.30 FAX bypass to G.711, T.38 Real Time FAX Relay Network features • Types of WAN- connections: ◦ PPPoE ◦ Static IP ◦ Dynamic IP ◦ PPTP/L2TP ◦ PPTP/L2TP + Static IP ◦ PPTP/L2TP + Dynamic IP • DHCP- Server and DHCP- Client • DNS relay • Skip VPN- tunnel (PPTP/L2TP) • Dynamic DNS • Static IP- routing • Remote access • Network statistics for each interface • IGMP Proxy • RIP • UPnP • VLAN support • Supports ping from the external network (WAN ping respond) Wireless connection • Supported safety standards : ◦ WEP ◦ WPA/WPA2 Personal ◦ WPA/WPA2 Enterprise • MAC- filter • PIN and PBC methods of WPS • WMM (Wi-Fi QoS) • Advanced Settings Firewall features • Network Address Translation (NAT) • Stateful Packet Inspection (SPI) • IP- filters • MAC- filter • URL- Filter • DMZ- zone • The protection and ARP- DDoS-attacks • Virtual servers Configuration and management • Web- based interface for configuration and management of multiple languages • Access via TELNET • Upgrade the firmware of the router through the web- interface • Save and load configuration • Support for remote logging • Automatic synchronization of system time with a NTP-server and manually configure the date and time • Ping • Traceroute utility
Warranty	3 months
Service During The Warranty Period (Who To Contact)	Importer Lab
Manufacturer Part Number	DVG-N5402SP-1S
Model	Wireless N Router Gateway 1*FXS
Condition	New
Manufacturer	D-Link
Additional Info	נתב אלחוטי בתקן 802.11n עם כניסת FXS ו-4 כניסות LAN
Speed	10/100 Mbit
Product Link	Wireless N Router VoIP Gateway D-Link Wireless N Router Gateway 1*FXS DVG-N5402SP-1S
Matching SKUs	ID:~65289~, NEW, OC: 39945, CD: DVG-N5402SP-1S, MPN: DVG-N5402SP-1S

Specification

Revew

WAN interface
• 1 10/100BASE-TX Ethernet port for cable or DSL- modem or connect to a dedicated Ethernet- line

LAN interface
• 4-port 10/100BASE-TX Ethernet

WLAN interface
• IEEE 802.11n ( up to 300 Mbit / s)
• IEEE 802.11b / g

FXS interface
• 1 FXS port to connect an analog phone or fax machine

Frequency band
• 802.11b: 2400 ~ 2484 MHz ISM band
• 802.11g: 2400 ~ 2484 MHz ISM band
• 802.11n
◦ HT20: 2400 ~ 2483.5 MHz ISM band
◦ HT40: 2422 ~ 2452 MHz ISM band

Wireless speed
• 802.11b: 11, 5.5, 2 and 1 Mbit / c for each channel, with automatic speed
• 802.11g: 54, 48, 36, 24 , 18, 12 , 9 and 6 Mbit / s for each channel, with automatic speed
• 802.11n
◦ HT20: up to 150 Mbit / s
◦ HT40: up to 300 Mbit / s

Modulation schemes
• 802.11b: CCK, DQPSK, DBPSK
• 802.11g: 64QAM, 16QAM, QPSK, BPSK, DSSS
• 802.11n: 64 QAM, 16QAM, QPSK, BPSK

Software
Basic functions SIP
• Invite with Challenge
• Register for IP-address SIP- server or domain name
• Support the format of SIP URI (RFC3986)
• Support for outbound (outbound) proxy
• Timers sessions (update / re-invite)
• Support for DNS SRV
• Types of calls: Voice / Modem / Fax
• User-configurable dial plan (dial plan)
• Identify the source and destination (P2P- calls) manually
• Dialing E.164 ( with an exclusion rule ENUM)

Call functions
• Direct call IP-to-IP without SIP proxy
• Hold / resume a call
• Call Waiting
• Forwarding (unconditional , on busy , no answer )
• "Do not disturb"
• Message Waiting Indication (MWI)
• Lock Hidden Numbers
• AntiAON
• Speed Dial
• "hotline"

Voice features
• Codecs : G.711 a / μ-law, G.729A, G.726, G.722
• DTMF detection and generation
• Comfort noise generation (CNG)
• Voice Activity Detection (VAD)
• Variable (dynamic ) jitter- buffer
• Generation of call progress tone (FXS)
• Program Gain
• In-band DTMF, out-of-band DTMF (RFC2833, SIP-INFO)
• Support for tone / pulse dialing
• Detection and generation Caller ID (Caller ID)
• T.30 FAX bypass to G.711, T.38 Real Time FAX Relay

Network features
• Types of WAN- connections:
◦ PPPoE
◦ Static IP
◦ Dynamic IP
◦ PPTP/L2TP
◦ PPTP/L2TP + Static IP
◦ PPTP/L2TP + Dynamic IP
• DHCP- Server and DHCP- Client
• DNS relay
• Skip VPN- tunnel (PPTP/L2TP)
• Dynamic DNS
• Static IP- routing
• Remote access
• Network statistics for each interface
• IGMP Proxy
• RIP
• UPnP
• VLAN support
• Supports ping from the external network (WAN ping respond)

Wireless connection
• Supported safety standards :
◦ WEP
◦ WPA/WPA2 Personal
◦ WPA/WPA2 Enterprise
• MAC- filter
• PIN and PBC methods of WPS
• WMM (Wi-Fi QoS)
• Advanced Settings

Firewall features
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI)
• IP- filters
• MAC- filter
• URL- Filter
• DMZ- zone
• The protection and ARP- DDoS-attacks
• Virtual servers

Configuration and management
• Web- based interface for configuration and management of multiple languages
• Access via TELNET
• Upgrade the firmware of the router through the web- interface
• Save and load configuration
• Support for remote logging
• Automatic synchronization of system time with a NTP-server and manually configure the date and time
• Ping
• Traceroute utility

Review

Warranty

3 months

Service During The Warranty Period (Who To Contact)

Importer Lab

Manufacturer Part Number

DVG-N5402SP-1S

Model

Wireless N Router Gateway 1*FXS

Condition

New

Manufacturer

D-Link

Additional Info

נתב אלחוטי בתקן 802.11n עם כניסת FXS ו-4 כניסות LAN

Speed

10/100 Mbit

Product Link

Wireless N Router VoIP Gateway D-Link Wireless N Router Gateway 1*FXS DVG-N5402SP-1S

Matching SKUs

ID:~65289~, NEW, OC: 39945, CD: DVG-N5402SP-1S, MPN: DVG-N5402SP-1S
