| Гарантия | 3 года |
| Сервисное Обслуживание в Гарантийный Период (К Кому Обращаться) | Компьютерный сервис Компмастер 073-2241747 Gei Oni 6, Tet Shoping Center, Ashdod |
| Артикул Производителя | MAG Z890 TOMAHAWK WIFI |
| Модель | MAG Z890 TOMAHAWK WIFI |
| JAN | 4711377259712 |
| Состояние | Новое |
| Цвет | черный |
| Производитель | Msi |
| Аудио | Realtek® ALC1220P Codec
7.1-Channel High Definition Audio
Supports S/PDIF output |
| Беспроводня сеть | Intel® Killer™ BE1750x Wi-Fi 7
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Supports Bluetooth® 5.4**, MLO, 4KQAM
* 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 SV3.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor's website for details. Bluetooth 5.4 support schedule depends on MSFT Windows 11 plan. |
| Внутренние Порты / Входы | 1x Thunderbolt5 card connector(JTBT5, support RTD3)
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
6x System Fan
1x EZ Conn-header (JAF_2)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports |
|
| Задние Выходы / Входы | - USB 10Gbps Type-A
- USB 5Gbps Type-A
- 5G LAN
- Wi-Fi / Bluetooth
- Audio Connectors
- HDMI™
- Thunderbolt™ 4 40Gbps (Type-C)
- USB 10Gbps Type-C
- Flash BIOS Button
- Clear CMOS Button
- USB 5Gbps Type-A
- S/PDIF-OUT
|
| Конфигурация | ATX |
| Память | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support 92 - 64 (OC) MT/s / 64 - 48 (JEDEC) MT/s
Max. overclocking frequency:
• 1DPC 1R Max speed up to 92+ MT/s
• 1DPC 2R Max speed up to 72+ MT/s
• 2DPC 1R Max speed up to 64+ MT/s
• 2DPC 2R Max speed up to 56+ MT/s
Supports Intel® POR Speed and JEDEC Speed
Supports Memory Overclocking and Intel® XMP 3.
Supports Dual-Controller Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM
• The DIMM slots on this motherboard only have single-sided latches.
• Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/. |
|
| Проводная Сеть | Intel® Killer™ E5000 5Gbps LAN |
| Размеры | ATX 243.84mmx304.8mm |
| Совместимость для сборки ПК | Материнские Платы Intel |
| Сокет | LGA1851 |
| Хранение Данных | 4x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
*Please refer to the manual for M.2 SSD heatsink restrictions. |
| Чипсет | Z890 |
| סוג הזיכרון | DDR5 |
| Ссылка На Сайт Производителя | Получить полную информацию о продукте - Перейти на страницу продукта |
| Ссылка На Продукт | Материнская Плата MSI MAG Z890 TOMAHAWK WIFI DDR5 LGA1851 |
| Соответствующие Артикулы | ID: 74230, OC: 41357, AMT: 4711377259712, MPN: MAG Z890 TOMAHAWK WIFI, JAN: 4711377259712 |
