Точка доступа D-Link Access Point WirelessN Single Band unified DWL-3600AP

Wi-Fi Interface

• 802.11b/g/n 2.4 GHz

LAN Interface

• 10/100/1000 Gigabit Ethernet

Antenna

• 2x2 MIMO embedded antenna with 4 internal antennas

Antenna Gain

• 4.7 dBi

Power Method

• IEEE 802.3af Power Over Ethernet or external power adapter

Wireless Frequency

• 802.11b/g/n: 2.4 GHz - 2.497 GHz

Data Transfer Rate

• 802.11n: 6.5 Mbps-130 Mbps (20 MHz)
• 6.5 Mbps- 300 Mbps (40 Mbps)
• 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
• 802.11b: 11, 5.5, 2 and 1 Mbps

System Management

• HTTP/HTTPS Web-based User Interface
• SNMP, SSH, Telnet Command Line

SSID

• 16 SSID
• Station Isolation

Wireless Security

• WEP
• Dynamic WEP
• WPA Personal/Enterprise
• WPA2 Personal/Enterprise

Detection & Prevention

• Rogue and Valid AP Classification

Authentication

• MAC Address Filtering
• 802.1x

Power Adapter

• 5V/2.5A

Power over Ethernet

• 48 VDC +/- 10%

Stand-Alone Mode

• WEP/WPA/WPA2 Security
• Rogue AP Detection
• Station Isolation
• MAC Address Filtering
• AP Load Balancing Setup
• WDS
• AP Clustering
• QoS/WMM
• Local Storage Configuration

Managed Mode (Managed by D-Link Wireless Switch/ Wireless Controller)

• Centralized Management
• Centralized Firmware Dispatch
• Visualized AP Management Tool
• Auto-Power Adjustment
• Dynamic Auto-Channel Selection
• L2 Fast Roaming
• L3 Fast Roaming
• Captive Portal
• WEP/WPA/WPA2 Security
• Rogue AP Detection
• Rogue AP Mitigation
• WIDS
• Station Isolation
• MAC Address Filtering
• AP Load Balancing Setup
• WDS
• QoS/WMM

Dimensions

• 203 x 203 x 48 mm (7.99” x 7.99 “x 1.89”)

Weight

• 635 g (1.4 lbs)

Operating Temperature

• (32°F to 104°F) 0° to 40°C

Operating Humidity

• 10% to 90% non-condensing

EMI/EMC/RF

• FCF Class B
• CE Class B
• C-tick
• IC
• VCCI
• NCC
• TELEC
• Wi-Fi ®

Safety

• cUL, LVD (EN60950-1)
• UL2043
• EN60601-1-2
