לוח אם Asus PROART Z790-CREATOR WIFI DDR5 DIMM LGA1700

073-2241747

גיא אוני 6, אשדוד

Total supports 4 x M.2 slots and 8 x SATA&6Gb/s ports*
Intel^®&13th & 12th Gen Processors
M.2_1 slot (Key M), type&2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
Intel^®&Z790 Chipset
M.2_2 slot (Key M), type 2242/2260/2280&(supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type&2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280&(supports PCIe 4.0 x4 & SATA modes)**
8 x SATA 6Gb/s ports**
* Intel® Rapid Storage Technology supports&NVMe RAID 0/1/5, SATA RAID 0/1/5/10.
** M.2_4 slot shares bandwidth with&SATA6G_5~8. SATA6G5~8 will be suspended once either a SATA or NVMe device is&detected at M.2_4.

4 x DIMM, Max. 128GB, DDR5
7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel^®&Extreme Memory Profile&(XMP)
OptiMem II
* Refer to www.asus.com for the Memory QVL&(Qualified Vendors Lists), and memory frequency support depends on the CPU&types.

Fan and Cooling related
1 x 4-pin CPU Fan header(s)
1 x 4-pin CPU OPT Fan header(s)
1 x 4-pin AIO Pump header(s)
5 x 4-pin Chassis Fan header(s)
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
1 x 6-pin +12V Power connector
Storage related
4 x M.2 slots (Key M)
8 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2x2 (support(s) USB&Type-C^®)
1 x USB 3.2 Gen 1 header(s) support(s)&additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 header(s) support(s) additional&4 USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 header(s)
1 x AURA RGB header(s)
1 x Clear CMOS header
1 x COM Port header
1 x CPU Over Voltage jumper
1 x Front Panel Audio header (AAFP)
1 x M.2 slot (Key E)
1 x SPI TPM header (14-1pin)
1 x 20-3 pin System Panel header with&Chassis intrude function
1 x&Thermal Sensor header

Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth® v5.3**
* WiFi 6E 6GHz regulatory may vary between&countries.
** The Bluetooth version may vary, please&refer to the Wi-Fi module manufacturer's website for the latest specifications.

לקבל מידע מלא על מוצר - מעבר לעמוד המוצר
