Module Fan CHENBRO SR113 Rear GPU Fan Module 80mm

Fan Module CHENBRO SR113 Rear GPU Fan Module

The CHENBRO 384-11311-2100A0 is an optional fan module mounted at the rear of the SR113 server chassis to cool GPGPU and graphics cards. It carries two 80 mm fans that spin at up to 11000 RPM and are PWM-controlled by the motherboard.

The module is listed as an official accessory for every SR113 version (4 or 5 GPGPU) and is hot-swappable, so a fan can be replaced without shutting the server down. It suits workstation and AI server builds with several double-width graphics cards.

Key features

• Targeted GPU cooling - The module sits at the back of the chassis in line with the expansion cards and exhausts the heat produced by GPGPU cards under full load.
• Two 80 mm fans - Two fans running at up to 11000 RPM deliver strong airflow in a crowded 4U chassis.
• PWM control - Fan speed is controlled by the motherboard according to temperature, so noise drops at low load.
• Hot-swap design - The fans can be replaced while the server is running, with no downtime.
• Made for the SR113 - Genuine Chenbro part for the SR11369. The 11-slot version has screw holes prepared for two modules, and installation requires freeing 3 PCIe slots for the cable bracket.

Specifications
