Processor Intel Core i3 7100 LGA1151

Intel Core i3 7100 Processor

The Intel Core i3-7100 is a 7th Gen Intel Core desktop processor (code name Kaby Lake) for the LGA1151 socket. It has 2 cores and 4 threads thanks to Hyper-Threading, a 3.9GHz clock and 3MB of cache, which makes it a good fit for office PCs, document work, web browsing and home computers.

Integrated Intel HD Graphics 630 lets you work without a separate graphics card and supports up to 3 displays and 4K at 60Hz. The processor supports dual-channel DDR4-2133/2400 or DDR3L-1333/1600 memory up to 64GB and has a TDP of only 51W. The tray version comes without a box and without a cooler.

Key features

• 2 cores and 4 threads - Hyper-Threading lets each core handle two threads, and the 3.9GHz clock keeps everyday work and light multitasking responsive.
• Intel HD Graphics 630 - Graphics clock from 350MHz up to 1.1GHz, DirectX 12 and OpenGL 4.5 support, up to 3 displays and 4K at 60Hz, with no graphics card required.
• DDR4 or DDR3L memory - Supports dual-channel DDR4-2133/2400 and DDR3L-1333/1600 memory up to 64GB, including ECC memory.
• Low power - A TDP of only 51W means a standard cooler is enough and the PC stays quiet and energy efficient.
• Security and virtualization - Supports Intel AES-NI, Secure Key, SGX and Boot Guard, plus VT-x and VT-d for running virtual machines.
• LGA1151 socket - Fits an LGA1151 motherboard that supports 7th Gen processors, with 16 PCIe 3.0 lanes for a graphics card and drives, and also supports Intel Optane Memory.

Specifications
