Processor Intel Core i9 12900KF LGA1700

Intel Core i9 12900KF Processor

The Intel Core i9-12900KF is a 12th Gen (Alder Lake) desktop processor for the LGA1700 socket with 16 cores (8 Performance-cores and 8 Efficient-cores), 24 threads and a turbo frequency of up to 5.2GHz. It suits gaming PCs and demanding software.

In the KF version the multiplier is unlocked for overclocking and there are no integrated graphics, so a separate graphics card must be used. The processor supports DDR5 memory up to 4800MT/s or DDR4 up to 3200MT/s and PCIe 5.0.

Key features

• Hybrid 16-core architecture - 8 Performance-cores (P) handle heavy tasks while 8 Efficient-cores (E) take care of background work, 24 threads in total. Intel Thread Director helps the operating system place each task on the right core.
• Turbo frequency up to 5.2GHz - Intel Turbo Boost Max 3.0 raises the fastest cores to up to 5.2GHz, and the Performance-cores reach a turbo of up to 5.1GHz. The result is high performance in games and in software that relies on a single core.
• 30MB of cache - 30MB of Intel Smart Cache plus 14MB of L2 cache shorten data access times and improve performance in video processing, code compiling and gaming.
• DDR5 or DDR4 and PCIe 5.0 - The memory controller supports DDR5 up to 4800MT/s or DDR4 up to 3200MT/s, in two channels and up to 128GB, so you can choose a motherboard for either memory type. PCIe 5.0 and 4.0 with up to 20 lanes suit graphics cards and fast NVMe drives.
• KF version without integrated graphics - The F suffix means the processor requires a discrete graphics card. It is a good fit for a gaming PC or workstation that has a dedicated graphics card anyway.
• Unlocked for overclocking - As a K-series processor, the multiplier is unlocked for overclocking on a supporting motherboard. Base power is 125W and maximum turbo power reaches 241W, so a high-quality cooling system is recommended.
