Processor Intel Core i5-9400F LGA1151 Condition:Used

Processor Intel Core i5-9400F

The Intel Core i5-9400F is a 9th generation Intel Core (Coffee Lake) desktop processor built on a 14 nm process, with 6 cores and 6 threads, a 2.90GHz base clock and up to 4.10GHz with Intel Turbo Boost 2.0, 9MB of Intel Smart Cache and a TDP of just 65W. The processor is used and has been tested in our lab.

It is a popular choice for affordable gaming and work PCs with a separate graphics card: the F suffix means there is no integrated graphics, so a graphics card is required. It suits upgrading or repairing a PC with an LGA1151 motherboard that supports 9th generation CPUs (check the board's CPU support list), or replacing a failed processor.

The processor supports dual-channel DDR4-2666 memory up to 128GB, PCI Express 3.0 with 16 lanes, Intel Optane Memory, AVX2 and AES-NI instructions and VT-x and VT-d virtualization.

Key features

• 6 cores up to 4.10GHz - Six physical cores at a 2.90GHz base clock; Intel Turbo Boost 2.0 raises the clock up to 4.10GHz in games and under load.
• Only 65W TDP - Low power draw allows quiet cooling with a regular CPU cooler, per the Intel PCG 2015C thermal specification.
• DDR4-2666 up to 128GB - Dual-channel DDR4-2666 memory support, up to 128GB and up to 41.6 GB/s of bandwidth.
• PCI Express 3.0 for graphics - 16 PCIe 3.0 lanes in 1x16, 2x8 or 1x8+2x4 configurations. The CPU has no integrated graphics and is meant to work with a separate graphics card.
• Intel Optane Memory - Supports Intel Optane Memory storage acceleration for faster system and application loading.
• Security and virtualization - Intel VT-x with EPT, VT-d, Intel SGX, Boot Guard, AES New Instructions, Secure Key and Execute Disable Bit.

Specifications
