AMD Ryzen 7 7800X3D Processor

The AMD Ryzen 7 7800X3D is a Ryzen 7000 Series gaming processor with AMD 3D V-Cache technology, which adds an extra layer of cache to the processor. This brings the L3 cache to 96MB, shortening data access times and improving game performance.

The processor has 8 Zen 4 cores and 16 threads, a 4.2GHz base clock, up to 5.0GHz boost and a 120W TDP. It is designed for the AM5 platform with DDR5 memory and PCIe 5.0, includes integrated AMD Radeon Graphics and ships without a cooler.

Key features

• AMD 3D V-Cache - 96MB of L3 cache thanks to an extra cache layer, for low latency and higher game performance at any resolution and setting.
• 8 Zen 4 cores - 8 cores and 16 threads with a 4.2GHz base clock and up to 5.0GHz boost, plus 8MB of L2 cache and support for AVX-512 instructions.
• AM5 platform and PCIe 5.0 - 28 PCIe 5.0 lanes (24 usable), 4 USB 10Gbps ports from the processor and compatibility with A620, B650, B650E, X670, X670E, B840, B850, X870 and X870E motherboards.
• DDR5 and AMD EXPO - Two DDR5 channels with up to 128GB of memory and up to DDR5-5200 with two modules, plus AMD EXPO profiles for easy high-speed memory setup.
• Performance tuning - The processor supports Precision Boost Overdrive, Curve Optimizer and AMD Ryzen Master. A cooler is not included, and AMD recommends a liquid cooler for optimal performance.
• Integrated graphics - AMD Radeon Graphics with 2 graphics cores at 2200MHz displays an image even without a graphics card.
