Processor Intel Core i7 9700F LGA1151

Intel Core i7 9700F Processor

The Intel Core i7-9700F is a 9th generation Intel Core desktop processor (code name Coffee Lake) for the LGA1151 socket, made in a 14nm process. It has 8 cores and 8 threads, a 3.0GHz base clock and up to 4.7GHz turbo, with 12MB of Intel Smart Cache.

The 65W TDP keeps cooling relatively simple. The F suffix means the processor has no integrated graphics, so a discrete graphics card is required. It supports DDR4-2666 memory up to 128GB and 16 PCIe 3.0 lanes. Part number CM8068403874523 is the tray version, which comes without a box and without a cooler.

Key features

• 8 physical cores - 8 cores with up to 4.7GHz turbo suit gaming and multi-core applications.
• 65W TDP - Moderate power draw allows a standard cooler and a wide choice of cases.
• DDR4 memory - Dual-channel DDR4-2666, up to 128GB and 41.6GB/s of bandwidth.
• PCIe 3.0 - 16 PCIe 3.0 lanes in 1x16, 2x8 or 1x8+2x4 configurations.
• Intel Optane and virtualization - Intel Optane memory support, plus Intel VT-x and VT-d for running virtual machines.
• LGA1151 socket - Fits LGA1151 motherboards with Intel 300 series chipsets. A discrete graphics card and a suitable cooler are required.

Specifications
