Processor Intel Core I5 14400F LGA1700

Processor Intel Core i5-14400F LGA1700 Tray

The Intel Core i5-14400F is a 14th Gen (Raptor Lake) desktop processor for socket LGA1700 with a hybrid design of 6 Performance-cores and 4 Efficient-cores, 16 threads, up to 4.7GHz turbo and 20MB Intel Smart Cache. Base power is 65W.

It is an excellent mid-range CPU for gaming and work PCs: the P-cores handle games and heavy applications, the E-cores run background tasks, and Intel Thread Director distributes work between them. It supports both DDR5 4800 and DDR4 3200, so it fits B760/H610/Z790 boards with existing memory.

The F model has no integrated graphics and requires a discrete graphics card. This is the Tray version (part number CM8071505093011, C0 stepping), sold as surplus: a new processor in open packaging, without retail box or cooler, so a CPU cooler is needed.

Key features

• Hybrid 6P+4E architecture - 6 Performance-cores up to 4.7GHz and 4 Efficient-cores up to 3.5GHz, 10 cores and 16 threads in total for gaming and multitasking.
• Intel Thread Director - The processor and the operating system route each task to the right core type for better performance and smooth responsiveness.
• 20MB Smart Cache - 20MB Intel Smart Cache plus 9.5MB of L2 boost performance in games and memory-sensitive applications.
• DDR5 or DDR4 - Supports DDR5 up to 4800 MT/s and DDR4 up to 3200 MT/s, up to 192GB in two channels with 76.8 GB/s bandwidth.
• PCIe 5.0 and 4.0 - Up to 20 PCIe lanes from the CPU (1x16+4 or 2x8+4) for a graphics card and a fast NVMe drive.
• 65W efficiency - 65W base power and 148W maximum turbo power, with Intel Turbo Boost 2.0 and Speed Shift.
• Security and virtualization - Intel VT-x and VT-d, Boot Guard, Control-Flow Enforcement, AES-NI and Secure Key.

Specifications
